Topic

Electrification

Electrification means running a building on electricity alone: heat pumps for heating, cooling, and hot water, and electric or induction cooking, with no fuel burned on site. It removes combustion fumes from the home, and the building's emissions fall as the grid gets cleaner.

Passive House makes it easier. With heating and cooling loads cut so far, the heat pump can be small; it can deliver heat at low temperatures, where it runs most efficiently, and it copes better with cold weather. For a field station in Michigan, the engineer's code calculation called for an 8-ton heat pump; the Passive House energy model put the need closer to 1 ton. A building with small loads also puts a smaller peak demand on the grid.

PHI doesn't require an all-electric building. Its renewable primary energy measure (PER) counts every energy use in the building and weights each by how hard it is to supply from renewable sources, so burning fuel scores poorly, reflecting its true cost to a renewable energy system. The Plus and Premium classes add renewable generation.

Heat pumps should be chosen for the local climate, with their capacity checked at the coldest design temperature. Refrigerants with a low global-warming potential further reduce the system's lifetime carbon.
